OPERATION MANUAL
IFF-701Ti
1-2-3
Page 12
Jul 1/00
LOCALIZER
TONE DIFFERENCE VALUES COURSE DEVIATION INDICATOR
% MODULATION
90 Hz 150 Hz DDM DECIBELS DEFLECTION µA
20.00 20.00 0 0 Centered 0
15.35 24.65 0.093 4.114 Standard 90
12.25 27.75 0.155 7.102 Full Scale 150
10.00 30.00 0.200 9.542 > Full Scale 194
0.00 40.00 0.4 Infinity Full One Tone, Delete Other 387
NOTE: Standard CDI Deflection = 60% of Full Scale (Linear Movement).
NOTE: Deflections in µA apply to Indicators with Full Scale Deflection Current of 150 µA.
Correspondence Chart for 90 Hz and 150 Hz Tones (LOC)
Table 3
GLIDE SLOPE
TONE DIFFERENCE VALUES COURSE DEVIATION INDICATOR
% MODULATION
90 Hz 150 Hz DDM DECIBELS DEFLECTION µA
40.00 40.00 0 0 Centered 0
35.45 44.55 0.091 1.988 Standard 78
31.25 48.75 0.175 3.622 Full Scale 150
20.00 60.00 0.400 9.542 > Full Scale 343
0.00 80.00 0.8 Infinity Full One Tone, Delete Other 686
NOTE: Standard G/S Indicator Deflection = 53% of Full Scale (Linear Movement).
NOTE: Deflections in µA apply to Indicators with Full Scale Deflection Current of 150 µA.
Correspondence Chart for 90 Hz and 150 Hz Tones (G/S)
Table 4
