CONTROLS
IC75 ENG 2-1
2
NOMENCLATURE
No. Name No. Name No. Name
1 Battery 9 Cabin 17 Upper roller
2 Fuel tank 10 Dump cylinder 18 Oscillating link
3 Hydraulic tank 11 Safety bar 19 Travel device
4 Engine 12 Body 20 Drive sprocket
5 Radiator, oil cooler 13 Rear gate 21 Headlight
6 Muffler 14 Rubber crawler 22 Direction indicator lamp
7 Air cleaner 15 Idle tumbler
8 Hydraulic pump 16 Lower roller
Right
Rea
Front
Left
