MAINTENANCE
IC75 ENG 4-11
Engine
Tightening torque
No. Special tightening Thread size
Wrench size
(mm)
N⋅m kgf⋅m
1 Engine and bracket (rear) M12 19 97 9.9
2 Bracket and turntable (rear) M16 24 241 24.6
3 Engine and bracket (front) M10 17 55 5.6
4 Bracket and turntable (front) M16 24 241 24.6
Hydraulic pump
Tightening torque
No. Tightening position Bolt size
Wrench required
(mm)
(N·m) (kgf·m)
1 Engine and pump housing M10 17 55 5.6
2 Pump housing and hydraulic pump M14 22 156 15.9
