IHP BarcelonaLights36ZEN - Page 13

900861-00NC
13
IHP.us.com
END VIEW
TOP OF
FIREPLACE
Non-combustible
facing material
Combustible
Material
Permitted
Metal Studs
Combustible Shelf
Combustible Shelf
12”
(305mm)
12”
(305mm)
18” TYP.
(457mm)
12”
(305mm)
6”
(153mm)
6”
(153mm)
Figure 12 - See-through fireplace mantel clearances
Figure 10 - Fireplace dimensions; refer to Table 5
Model:
Natural Gas
(NG)
A
Overall
Length
B
Inside
Opening
C
Overall
Height
D
Opening
Height
E
Overall
Depth
F
Leg
Height
G
Valve
Box Depth
H
Clearance To
Combustible Side Wall
I
Clearance To
Combustible Ceiling
BarcelonaLights36ZEN or VRE4636ZEN
40”
(1016mm)
36”
(915mm)
37-1/2”
(953mm)
16”
(407mm)
16”
(407mm)
11-1/2”
(292mm)
8-3/4”
(222mm)
36”
(915mm)
42-1/2”
(1080mm)
BarcelonaLights48ZEN or VRE4648ZEN
52”
(1321mm)
48”
(1219mm)
37-1/2”
(953mm)
16”
(407mm)
16”
(407mm)
11-1/2”
(292mm)
8-3/4”
(222mm)
36”
(915mm)
42-1/2”
(1080mm)
BarcelonaLights60ZEN or VRE4660ZEN
64”
(1626mm)
60”
(1524mm)
37-1/2”
(953mm)
16”
(407mm)
16”
(407mm)
11-1/2”
(292mm)
8-3/4”
(222mm)
36”
(915mm)
42-1/2”
(1080mm)
BarcelonaLights72ZEN or VRE4672ZEN
76”
(1931mm)
72”
(1829mm)
37-1/2”
(953mm)
16”
(407mm)
16”
(407mm)
11-1/2”
(292mm)
8-3/4”
(222mm)
36”
(915mm)
42-1/2”
(1080mm)
Table 5 - Fireplace dimensions and clearances.
Figure 11 - See-through fireplace clearance to combustibles
(See Table 5)
FRONT VIEW
TOP VIEW
END VIEW
E
E
C
F
D
A
B
Bottom Finish Fin
Hood
1/2” (13mm)
(Typ. Each Side)
6”
(153mm)
20”
(508mm)
G
1/2” (13mm)
(Typ. Each Side)
I
H
END VIEW
SIDEWALL
CEILING
FLOOR
11-1/2”
(292mm)
This fireplace ships from the factory as a single sided fireplace, but by removing the back panels you can convert it into a see-through fireplace. Your
specific application, single sided verses see-through, will determine your installation. Ensure you follow the proper clearances during installation.
SEE-THROUGH FIREPLACE DIMENSIONS AND MINIMUM CLEARANCES TO COMBUSTIBLES
Continued
