ENGLISH
8 BEFORE YOU OPERATE THE MONITOR
CONTROLS AND CONNECTORS : MONITOR
<Front>
<Back>
POWER Power Button
UP Up/Volume - Button
DOWN Down/Volume + Button
LEFT / AUTO Left/Auto Button
RIGHT / SELECT Right/Input Select Button
MENU Menu Button
LED
Green Normal Operation
Orange Power Management
IR Remote Sensor
SPEAKERS Speakers
AC IN AC-INLET AC Connector( : Alternating current) (AC-IN)
AC SWITCH
(ON) / (OFF)
MAIN POWER Main Power Switch
USB USB Touch USB Connector
RS232 RS232C 9pin
RS232C Connector
IR Mini Jack IR Extender Connector
DP DisplayPort DisplayPort
Connector
HDMI1
HDMI2
HDMI3
HDMI
HDMI Connector
VGA VGA VGA Connector
Audio Mini Jack Audio Connector
MP(USB) Media USB Media Player
POWER
UP
DOWN
LEFT/AUTO
RIGHT/SELECT
MENU
LED
IR
