AmpliTube X-TIME
Delay Models
22
SWELL
Gentle and ambient swell delays to cream up slow lines. The swell effect has independent time and depth so it
can be synced with the delay or pushed crazier to un-synced rates.
Parameters
• TIME: controls the time of the delay repetitions.
From 60 ms to 2000 ms or from 1/32 to 1/2T when BPM SYNC is ON.
• FEEDBACK: controls the number of repetitions occurring in the delay.
From 0% to 100%.
• FILTER: controls the low-pass filter frequency. Turn it counterclockwise to get darker tones or clockwise get
the full frequency spectrum.
From 1000 Hz to 20000 Hz.
• MOD: controls the depth of the swell effect.
From 0 dB to -60 dB.
• MIX: controls the balance of dry and wet signal. At 0% the signal is fully dry, while at 100% the signal is
fully wet. At around 85% the dry and wet signal have the same level.
From 0% to 100%.
• SWL TIME: controls the time of the swell effect.
From 10 ms to 1000 ms or from 1/32 to 1/2T when BPM SYNC is ON.
• SWL SENS: adjusts the swell sensitivity level.
From -50 dB to -12 dB.
• X-MODE: the X-MODE pushes the feedback to infinity.
ON or OFF.
SWELL Control Changes
Parameter Control Change # Values
TIME 21 0 – 127
FEEDBACK 22 0 – 127
FILTER 23 0 – 127
MOD 24 0 – 127
MIX 25 0 - 127
SWL TIME 46 0 – 127
SWL SENS 47 0 - 127
X-MODE 13 0 - 127
When a parameter range is not linear its values are equally divided among the 128 steps of a Control Change
value.
