Manual Page 47
C.2.5.1 Modifying an entry of the transfer target
To change a file name, to select a subdirectory or to modify other entries for the transfer
target, click the blue symbol. The touchscreen shows the current settings.
To change an entry, click in the respective line, for example “File name”.
The touchscreen changes and shows a keyboard. The cursor is positioned behind the
entry to be changed.
Picture 35: Keyboard, displayed on the touchscreen
Confirms changes and returns to former screen.
Cancel changes and returns to former screen.
Shift button for upper/ lower case writing.
Switches the keyboard and shows all variables which could be used in
the name.
Use the keyboard to modify the entry.
To confirm changes, touch the OK button.
The return to former screen without changes, touch the Cancel button.
