Manual Page 59
If the Job Mode is active, the ScanWizard start screen changes in one detail.
Picture 50: Startscreen Job Mode
After touching Scan Now the screen shows in a separate window a disclaimer with
information about copyright and the legal situation while scanning documents.
This disclaimer must be accepted. Touch the respective button below the disclaimer text.
Picture 51: Disclaimer with copyright notes
While scanning in job mode, some icons right beside the preview section will be activated.
Deletes the selected image.
Marks where in the list an image should be inserted.
Moves upwards through the list of images.
Moves a selected image upwards in the list.
Moves downwards through the list of images.
Moves a selected image downwards in
the list.
Selects an image from the list. A frame marks the image in the list of
images displayed on the TFT monitor.
