Introduction
The DA-6804+D series of distribution amplifiers distributes serial digital signals
according to SMPTE259C, 292M, 424M and DVB-ASI standards (compatibility
depends on the model selected).
The following modules are available:
 DA-DH6804+D is a dual channel 3 Gb/s HD/SD-SDI distribution amplifier
 DA-DHR6804+D is a dual channel 3 Gb/s HD/SD-SDI distribution amplifier
with reclocking capability
 DA-DS6804+D is a dual channel SD-SDI distribution amplifier
 DA-DSR6804+D is a dual channel SD-SDI distribution amplifier with reclocking
capability
Each distribution amplifier consists of a front and back module, and operates in
FR
6802+ series frames, occupying two slots. Ten distribution amplifiers can be
loaded into a frame.
Each distribution amplifier contains two
inputs and eight outputs, and can be
configured for either single channel use (1×8_ACO or 1×8) or independent
dual-channel use (2_1×4). Each FR6802+ frame can provide up to 20 channels for
serial digital signal distribution.
DA-6804+D “g
reen” power-saving distribution amplifiers shut down automatically
if no input signal is detected. Power consumption is partially reduced if the module
is receiving input, but is not connected to a 75Ω load.
DA-6804+D m
odules can be set up, controlled, and monitored either at the card
edge, or remotely, using an Ethernet connection. Web browser and CCS remote
control require either an ICE6800+ module, or a 6800+ETH module installed in the
frame. CCS remote control provides additional control functions not included in
local control mode.
