Specifications
Inputs
Table 4-1 Electrical Channel Input Specifications
Item Specification
Number of inputs 2
Signal type
 DA-DH6804+D and DA-DHR6804+D:
3G-SDI, HD-SDI, SD-SDI, ASI
 DA-DS6804+D and DA-DSR6804+D:
SD-SDI, ASI
Connector BNC per IEC169-8
Impedance 75Ω
Return loss
 All models: >15 dB, 5 MHz to 1.5 GHz
 DA-DH6804+D and DA-DHR6804+D:
>10 dB, 1.5 GHz to 3.0 GHz
Maximum signal level 0.88 V
Cable equalization
 All models: 0 – 1,312 ft (0 – 400 m) for 270 Mb/s
 DA-DH6804+D and DA-DHR6804+D:
 0 – 656 ft (0 – 200 m) for 1.5 Gb/s
 0 – 410 ft (0 – 125 m) for 3.0 Gb/s
