Imagine DA-DHR6804+D - Electrical Channel Output Specifications

Chapter 4
Specifications
18
Copyright © 2011, Harris Corporation
Outputs
Table 4-2 Electrical Channel Output Specifications
Item Specification
Number of outputs 8
Signal type
 DA-DH6804+D and DA-DHR6804+D:
3G-SDI, HD-SDI, SD-SDI, ASI
 DA-DS6804+D and DA-DSR6804+D:
SD-SDI, ASI
Connector BNC per IEC169-8
Impedance 75Ω
Return loss
 All models: >15 dB, 5 MHz to 1.5 GHz
 DA-DH6804+D and DA-DHR6804+D:
>10 dB, 1.5 GHz to 3.0 GHz
Signal amplitude 800 mV ± 10%
DC offset 0.0 V ± 0.5 V
Rise and fall time
 All models: 400-700 ps for SD-SDI, ASI
 DA-DH6804+D and DA-DHR6804+D:
 <270 ps for HD-SDI
 <135 ps for 3G-SDI
Overshoot <10%
Reclocking rates
 DA-DS6804+D and DA-DSR6804+D:
270 Mb/s
 DA-DH6804+D and DA-DHR6804+D:
270 Mb/s, 1.485 Gb/s, 2.97 Gb/s
Jitter
 DA-DH6804+D and DA-DHR6804+D:
 <0.3 UI for 3G-SDI
 <0.2 UI for HD-SDI
 All models: <0.2 UI for SD-SDI, ASI
