Imagine DA-DHR6804+D - Main Features of DA-6804+D Series

Chapter 1
Introduction
2
Copyright © 2011, Harris Corporation
Main Features
All Models
The main features of the DA-6804+D series are listed below:
 Passes signals at data rates from 5 Mb/s to 540 Mb/s (DA-DS6804+D and
DA-DSR6804+D) or from 5 Mb/s to 3 Gb/s (DA-DH6804+D and
DA-DHR6804+D)
 Four selectable channel configurations:
 1×8_ACO: 1 input to 8 outputs with auto changeover
 1×8_ In_1: SDI In_1 is distributed to 8 outputs
 1×8_ In_2: SDI In_2 is distributed to 8 outputs
 2_1×4: 2 independent inputs, each distributed to four outputs as either
SDI In_1 to SDI Out_1 (1-4), or SDI In_2 to SDI Out_2 (1
-4)
 Input signal presence detection and report
 Automatic input cable equalization
 Selectable + 6dB gain to use external passive 75Ω 2×1 splitter (via CCS only)
 Selectable input EQ bypass
 Automatic power saving mode if no input signal is detected, or if no output
load is detected
 Local and remote control
 Hot swapping capability
DA-DSR6804+D and DHR6804+D Models
DA-DSR6804+D and DHR6804+D modules also include the following features:
 Reclocking capability for 270 Mb/s SMPTE signals (DA-DSR6804+D), or 270
Mb/s, 1.485 Gb/s, and 2.97 Gb/s SMPTE signals (DA-DHR6804+D)
 Three selectable reclocking modes (automatic, manual, enforce bypass)
 Automatic bypassing of the reclock stage if signal is not lockable
 Reclock status and data rate report
 Automatic slew rate control for output signal
