Imit CRX/E Plus - Chronothermostat Controls Key

4. CHRONOTHERMOSTAT CONTROLS KEY
✲
7
Reset button
Reduced temperature “T2”
setting button
Programming confirmation
button
Knob for normal
temperature “T1” setting
Differential selector
Summer (
✲ ) or winter ( )
mode selector
Override
button
Microswitches for current time
and operating setting
Access to the program
and day change button
