4.7 PARAMETERS FOR FILLING IN THE PACKAGE
FICHE.
In case you should wish to install an assembly, starting from the
Victrix Tera (28, 32 or 38) boiler, use the assembly charts in Fig.
60 and 63.
To complete it properly, ll the relevant spaces (as shown in the
assembly sheet facsimile Fig. 58 and 61) with the values shown
in tables (Fig. 59 and 62.
Facsimile for lling in the package che for room central heating systems.
e remaining values must be obtained from the technical data
sheets of the products used to make up the assembly (e.g. solar
devices, integration heat pumps, temperature controllers).
Use board Fig. 60 for “assemblies” related to the central heating
mode (e.g.: boiler + temperature controller).
Use board Fig. 63 for “assemblies” related to the domestic hot
water function (e.g.: boiler + solar thermal system).
Boiler and supplementary heat pump installed with low temperature heat emitters
at 35 °C?
FFrom the board of the heat
pump
Seasonal central heating energy efciency of the boiler
1
%
Temperature control
From temperature
control board
Supplementary boiler
From boiler board
Supplementary heat pump
From the heat pump
board
Solar contribution and supplementary heat pump
Select the lowest
value
The energy efciency of the set of products indicated in this sheet may not reect the actual energy
efciency after installation since such efciency is affected by additional factors, such as the heat loss
in the distribution system and the size of the products compared to the size and features of the building.
Seasonal central heating energy efciency of the set
Seasonal central heating energy efciency class of the set
Solar contribution
From the board of the solar device
Class I = 1 %, Class II = 2 %,
Class III = 1.5 %, Class IV = 2 %,
Class V = 3 %, Class VI = 4 %,
Class VII = 3.5 %, Class VIII = 5 %
2
%
+
3
%
±
Seasonal central heating energy efciency of the room
(%)
( - ‘I’ ) x 0.1 =
( - ‘I’ ) x ‘II’ =
0.5 x O 0.5 x =
+ ( 50 x ‘II’ ) =
4
5
6
7
4 5
%
%
%
%
+
+
-
Dimensions of the
manifold (in m
2
)
Volume of the
tank (in m
3
)
Efciency of the
manifold (in %)
Classication of the
tank
A* = 0.95, A = 0.91,
B = 0.86, C = 0.83,
D-G = 0.81
( ‘III’ x + ‘IV’ x ) x (0.9 x ( / 100) x =
Seasonal central heating energy efciency of the
room (%)
G F E D C B A A
+++
A
++
A
+
< 30 % ≥ 30 % ≥ 34 % ≥ 36 % ≥ 75 % ≥ 82 % ≥ 90 % ≥ 98 % ≥ 125 %≥ 150 %
%
7
‘I’
