Note that a piece of double-sided tape may be used to secure the receiver on top of the metal can
beside the connector.
Receiver antennas may be routed through any of the four available slots. Two at the back of the quad
in the LED diffuser, and two in the side-plates. Be sure to use some extra shrinkwrap over the fragile
antennas so they’re better able to handle the abuse of rough landings and handling the quad.
The best solution is to route them through the holes in the side-plates in front of the rear arms but
certain receivers may not have sufficiently long antenna wires, so routing them out the back is the only
option in that case.
Connector Part Numbers and Sources
If any of the connectors on the Vortex 230 Mojo are damaged, or if 3rd party components are to be integrated
into the system, the following list of connectors and pre-crimped wires should be useful. Obviously we also
have all the cables available in a set as a spare part with part number V23CAB.
Cable
Description
Manufacturer’s PN
Digikey PN
FUN/GPS Signal Connector
Picoblade 5 pin
0510210500 
WM1723-ND
Camera Signal Connector
Picoblade 3 pin
0510210300 
WM1721-ND
Picoblade Signal Wires
(all Picoblade connectors)
Picoblade
0006660013
WM2320-ND



 



