ImmersionRC vortex 250 pro - Specifications

Specifications
Flight Controller
IMU
Invensense 6050, 3 axis Gyro, 3 axis Accelerometer
Altimeter
Bosch BMP180
CPU
STM32F303 32-bit ARM processor
Firmware
Cleanflight compatible (with API version matching that of the OSD)
OSD
CPU
STM32F373 32-bit ARM processor
Resolution
440H x 280V
Style
White, with black surround around all pixels
Output
Programmable Black/White levels
Video Tx Features
Transmitter Module
Socketed, Custom NexWaveRF 5.8GHz module
Channels
40 Initially, programmed via OSD
Bands
5, including the ImmersionRC/FatShark bands, and RaceBand
Frequency, IRC/FS
5740, 5760, 5780, 5800, 5820, 5840, 5860, 5880 MHz
Frequency, RaceBand,
CH1..8
5658, 5695, 5732, 5769, 5806, 5843, 5880, 5917 MHz
Frequency, ‘A’ Band, CH1..8
5865, 5845, 5825, 5805, 5785, 5765, 5745, 5725 MHz
Frequency, ‘B’ Band, CH1..8
5733, 5752, 5771, 5790, 5809, 5828, 5847, 5866 MHz
Frequency, ‘E’ Band, CH1..8
5705, 5685, 5665, 5645, 5885, 5905, 5925, 5945 MHz
Power Output
350mW +/- 1dB (25mW module optional)
Audio
Stereo, Right channel used for Telemetry, Left channel routed to Mic
connector
Recommended Antenna
Supplied SpiroNET Omni, Skew Planar, 4 leaf
External vTx Support
5-pin PicoBlade connector, usable only when the RF module is removed.
Note: Using an external vTx does not allow OSD channel switching.
Power Train
Standard Prop
Gemfan 5045
Maximum Prop Size
6” (without GoPro, use the optional 6” arms for longer props)
Stock Motors
OEM V-Spec 2204-2300kV, single-strand
Recommended Battery
1300mAh 3S 45~90C, or 1300mAh 4S 45~90C
ESC
55
