Hexadecimal expression
A 16-bit binary number is expressed in hexadecimal format (4 digits). Table 3.9 shows the expres-
sion. The hexadecimals are shown as they appear on the LED monitor.
Table 3.9 Binary and Hexadecimal Conversion
Binary Hexadecimal Binary Hexadecimal
0 0 0 0 0 1 0 0 0 8
0 0 0 1 1 1 0 0 1 9
0 0 1 0 2 1 0 1 0 A
0 0 1 1 3 1 0 1 1 b
0 1 0 0 4 1 1 0 0 C
0 1 0 1 5 1 1 0 1 d
0 1 1 0 6 1 1 1 0 E
0 1 1 1 7 1 1 1 1 F
