Table 3.14 Continued
LED monitor
shows:
(item No.)
Display contents Description
6_18
Terminal I/O signal
status under commu-
nication control
(displayed with the
ON/OFF of LED seg-
ments)
6_19
Terminal input signal
status under commu-
nication control
(in hexadecimal for-
mat)
6_20
Terminal output signal
status under commu-
nication control
(in hexadecimal for-
mat)
Shows the ON/OFF status of the digital I/O terminals under
communication control. Refer to "
Displaying control I/O
signal terminals under communication control" in Sec-
tion 3.7 "Checking I/O Signal Status" for details.
When the same alarm occurs a number of times in succession, the alarm information fo
