COMPONENT, MODEL & OPTION DESCRIPTIONS
FEATURES and BENEFITS
• Stand-alone Self-contained • Energy Efficient Solid • Consistent loading of
design Vacuum-Conveying State Controls operating Machines, Hoppers or
System on a Batch Principle Day-Bins
• Spun & Welded Aluminum • Automatic Conveying for a • Take-apart design for Easy
Body Construction – wide range of materials and Cleaning & Maintenance
Standard conditions
BASIC COMPONENTS
The complete Whisper® Loaders Conveying System comprises the following major items (See Figure 1-1):
Receiving Hopper Body with Inlet, Mounting Flat-disc Nylon or Polyester-Felt media
Flange and Dump Valve Flapper Assembly Membrane Filter (Vibra-Pulse™ filter-
with Proximity Switch (material level sensor) cleaning system optional) and Gasket to
seal Cover to Body
Integrated Motor/Turbine, Brush-type
standard (Brushless type option available) Control Panel housed in NEMA 1 Enclosure
with ON/OFF Switch, Indicator Lights,
Material Pick-up Lance and PVC Flex Hose Control Cord and Power Cord
(quantity doubled for PLVP models)
© Copyright 2007 IMS Company. All rights reserved. An ISO 9001:2000 Registered Quality Company
7
