Parts 27 Section - 4
4004i - Manual # 99904386
99904325 COMPLETE PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QT Y.
1. 51721375 KIT-HRDW BASE & MAST 4004I REF
2. 91722220 KIT-ELECTRICAL INSTALLATION REF
3. 51721540 KIT-HYD 4004I REF
4. 51721268 CYL-3.5/1.7 16.06S 30.44CC C 1
5. 52721309 WLDMT-BASE 4004I 1
6. 52725114 MAST WELDMENT-4004I 1
7. 60140618 PIN-TYPE NN 1.00 X 8.25 1
8. 52721315 WLDMT-GEAR SHROUD 4004I 1
9. 60141143 PLATE- ELEC ROTATOR BRKT TOP 4004I 1
10. 60141128 PLATE-ELEC ROTATOR BRKT BOTTOM 1
11. 60132385 SPACER- POWER UNIT 1
12. 60132856 BRKT-GREASE HOSE MNTG 4004I 1
13. 71056633 GEAR-TRNTBL BRG 12.63” DIA 1
14. 70580194 CLAMP-I” CONDUIT HANGER W/BOLT 2
15. 72060178 CAP SCR .62-11X 4.00 HH GR8 Z 1 15
16. 73511283 POWER UNIT- 1.19CC 12VDC 1
17. 73511157 MOTOR-HYD 101 1702 009 1
18. 73734304 VALVE BANK-3 SEC SERIES 3GPM @ 500PSI 1
19. 76039295 GASKET-GEA19 008-10056-1 1
20. 70034382 CAP-GREASE PRO20 GC-RED 1 5
21. 72060000 CAP SCR .25-20X .50 HH GR5 Z 1 3
22. 72060002 CAP SCR .25-20X .75 HH GR5 Z 1 7
23. 72060044 CAP SCR .38-16X .75 HH GR5 Z 1 1
24. 72060046 CAP SCR .38-16X 1.00 HH GR5 Z 1 1
25. 72060050 CAP SCR .38-16X 2.00 HH GR5ZC 1 2
26. 72062104 NUT .25-20 HEX NYLOCK 1 3
27. 72062207 NUT 8-32 HEX NYLOCK 1 5
28. 72063001 WASHER .25 FLAT 1 10
29. 72063049 WASHER .25 LOCK 1 8
30. 72063051 WASHER .38 LOCK 1 4
31. 72063053 WASHER .50 LOCK 1 2
32. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 5
33. 72063119 WASHER .62 FLAT ASTM F436 1 31
34. 72053508 ZERK-NPT .12 1 1
35. 72053301 COUPLING-GLV .12 SCH 40 1 1
36. 72602009 SCR-MACH # 8-32X 1.25 BTNHD SS 1 5
37. 72601949 CAP SCR .50-13X 1.25 SH ZC 1 2
38. 51721664 CABLE ASM- 1GA-5/16RNGX 1/4RNGX 48.00LG 2 1
39. 51721943 CABLE ASM- 1GA-3/8RNGX SWVL FX 11.00LG 2 1
40. 51721944 CABLE ASM- 1GA-3/8RNGX SWVL MX 60.00LG 2 1
41. 77441534 SWITCH-225A CONTACTOR 12V OR 24V 1
42. 77441312 CABLE ASM-10GA-#10RNGX 1/4RNGX 6.00LG 2 1
43. 72534547 ELBOW-STREET STL .12 X 45 DEG 3 1
44. 53000700 GREASE EXT- 8.00 OAL 6.00HOSE 3 1
