IMT 4004i - Pin Removal and Inspection

Parts 41 Section - 4
4004i - Manual # 99904386
99904326 COMPLETE PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO QTY.
1. 51721320 KIT-HRDW 3203 BOOM ASY 1
2. 51725007 CYL-1.50/1.0 48.00S 7.38CC C 1
3. 52724109 WLDMT-LOWER BOOM 4004I 1
4. 52721312 WLDMT- 1ST EXT 4004I 1
5. 52725023 WLDMT- 2ND ST EXT 4004I 1
6. 52725024 WLDMT-2ND STAGE MANUAL EXT 4004I 1
7. 60030373 WEAR PAD- EXT CYLINDER 1
8. 60030374 WEAR PAD-RND 0.25X 1.00X .50X .31 2
9. 60030376 WEAR PAD-RND 0.30X 3.50X 1.00X 0.615 2
10. 60132302 STOP SCREW 3/8-24 X .50 4
11. 71734311 PIN-QUICK RLSE .62D/4.5 CRIT 1
12. 71734314 PIN-QUICK RLSE .62D/5.75 CRIT 1
13. 72060928 CAP SCR .50-13X 2.25 HH GR5 Z 1 1
14. 72062104 NUT .25-20 HEX NYLOCK 1 2
15. 72063001 WASHER .25 FLAT 1 4
16. 72063005 WASHER .50 FLAT 1 1
17. 72063051 WASHER .38 LOCK 1 4
18. 72063053 WASHER .50 LOCK 1 1
20. 60133938 WEAR PAD-RND 0.25X 1.00X .50X .50 STL 2
21. 60030434 WEAR PAD-RND 0.25X 3.00X 1.00X .25 2
22. 60030379 WEAR PAD-RND 0.19X 1.00X .50X .31 4
23. 72661711 CLEVIS PIN .50 X 3.00 REF
24. 70034490 PLATE-ANGLE PLASTIC 3.50” 2
25. 72661766 LOCKING PIN RUE RING .50 1
26. 72661543 PIN-QUICK 316-10QP 2
REV. O CN682
NOTE
1. Install wear pads after installing cylinder.
