IMT 4004i Parts & Specifications

Parts 43 Section - 4
4004i - Manual # 99904386
99904326-1 PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY.
1 51721320 KIT-HRDW 3203 BOOM ASY 1
2 51725007 CYL-1.50/1.0 48.00S 7.38CC C 1
3 52724109 WLDMT-LOWER BOOM 4004I 1
4 52721312 WLDMT- 1ST EXT 4004I 1
5 52725023 WLDMT- 2ND ST EXT 4004I 1
6 60132302 STOP SCREW 3/8-24 X .50 2
6 52725024 WLDMT-2ND STAGE MANUAL EXT 4004I 1
7 60030373 WEAR PAD- EXT CYLINDER 1
8 60030374 WEAR PAD-RND 0.25X 1.00X .50X .31 2
9 60030376 WEAR PAD-RND 0.30X 3.50X 1.00X 0.615 2
10 60132302 STOP SCREW 3/8-24 X .50 2
11 71734311 PIN-QUICK RLSE .62D/4.5 CRIT 1
12 71734314 PIN-QUICK RLSE .62D/5.75 CRIT 1
13 72060928 CAP SCR .50-13X 2.25 HH GR5 Z 1
14 72062104 NUT .25-20 HEX NYLOCK 2
15 72063001 WASHER .25 FLAT 4
16 72063005 WASHER .50 FLAT 1
17 72063051 WASHER .38 LOCK 4
18 72063053 WASHER .50 LOCK 1
20 60133938 WEAR PAD-RND 0.25X 1.00X .50X .50 STL 2
21 60030434 WEAR PAD-RND 0.25X 3.00X 1.00X .25 2
22 60030379 WEAR PAD-RND 0.19X 1.00X .50X .31 4
23 72661711 CLEVIS PIN .50 X 3.00 REF
24 70034490 PLATE-ANGLE PLASTIC 3.50” 2
25 72661766 LOCKING PIN RUE RING .50 1
26 72661543 PIN-QUICK 316-10QP 2
REV. O CN682
