Parts 55 Section - 4
4004i - Manual # 99904386
51725007 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1 94397290 IMT SEAL KIT-1.50 BORE 1.00 ROD .75 STGR 1
2 52722110 ROD ASM-1.00 DIA X 61.38 LG .75 S 1
3 52725008 CASE ASM-1.50 BORE X 58.25 LG 1
4 60135105 HEAD-1.50 BORE X 1.00 ROD (DUCTILE IRON) 1
5 60132170 STINGER LOCK .75-16 X 1.75 LG 1
6 60132173 STOP TUBE-1.00 ROD X 4.00 LONG 1
7 60135106 PISTON-1.50 BORE X .75 STGR (DUCT IRON) 1
8 73054999 VALVE-CBAL SUN01 CBBC-LHN 1
9 76397127 WEAR RING-PISTON 1.50OD X .75W 1 1
10 76397128 WEAR RING-ROD 1.00 ID X .38W 1 1
11 76397129 ROD WIPER-TYPE AN 1.00 ROD 1 1
12 76534502 U-CUP LOADED 1.00X1.25X.250 B 1 1
13 76534503 U-CUP LOADED 1.25X1.50X.250 B 1 2
14 7Q072018 O RING .75X .88X .06 70 1 1
15 7Q072129 O RING 1.56X 1.75X .09 70 1 1
REV. A EFFECTIVE 2013
51725007 CYLINDER DATA
CASE ø5 cm (1.88”) O.D. X ø3.8 cm (1.5”) BORE X 148 cm (58.25”) LONG
ROD ø2.54 cm (1”) X 155 cm (61”) LONG
STROKE 122 cm (48”)
DRY WEIGHT 16.5 kg (36.45 LB)
TEST PRESSURE 207 Bar (3000 PSI)
OPERATING PRESSURE 172 Bar (2500 PSI)
TORQUES
PISTON 13.8-18 kg- m (100-130 FT-LB)
HEAD 27.7 kg - m (200 FT-LB)
CARTRIDGE 4.1-4.8 kg-m (30-35 FT-LB)
NOTES:
1. To reduce downtime, replace all components of the seal kit whenever the cylinder is disassembled.
2. Apply lubricating compound to threads on cylinder head only. Keep away from all seals.
3. Apply “Lubriplate” No. 630-2 medium heavy, multi-purpose lubricant, to all piston, head gland, and holding
valve seals, nylon lock ring, cast iron piston rings, and rod stinger threads.
