IMT 4004i - Page 61

Parts 57 Section - 4
4004i - Manual # 99904386
51722111 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 94397290 IMT SEAL KIT-1.50 BORE 1.00 ROD .75 STGR 1
2. 52722110 ROD ASM-1.00 DIA X 61.38 LG .75 S 1
3. 52721293 CASE ASM-1.50 BORE X 58.25 LG 1
4. 60135105 HEAD-1.50 BORE X 1.00 ROD (DUCTILE IRON) 1
5. 60132170 STINGER LOCK .75-16 X 1.75 LG 1
6. 60132173 STOP TUBE-1.00 ROD X 4.00 LONG 1
7. 60135106 PISTON-1.50 BORE X .75 STGR (DUCT IRON) 1
8. 73054999 VALVE-CBAL SUN01 CBBC-LHN 1
9. 76397127 WEAR RING-PISTON 1.50OD X .75W 1 1
10. 76397128 WEAR RING-ROD 1.00 ID X .38W 1 1
11. 76397129 ROD WIPER-TYPE AN 1.00 ROD 1 1
12. 76534502 U-CUP LOADED 1.00X1.25X.250 B 1 1
13. 76534503 U-CUP LOADED 1.25X1.50X.250 B 1 2
14. 7Q072018 O RING .75X .88X .06 70 1 1
15. 7Q072129 O RING 1.56X 1.75X .09 70 1 1
REV. C
