Electrical & Lighting 77 Section - 5
4004i - Manual # 99904386
99904392 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 91722220 KIT- 4004I ELECTRICAL INSTALLATION 1
2. 71570922 WINCH-DC2000 12VDC REF
3. 89034049 SPIRAL WRAP-BLACK 1.25 FT
4. 73511283 POWER UNIT- 1.19CC 12VDC 1
5. 77041932 CONTACTOR-WINCH 12V DC2000 REF
6. 51721717 CABLE ASM- 2GA-5/16RNGX 3/8RNGX 26.50LG #1 1
7. 51721497 CABLE ASM- 2GA-5/16RNG X 3/8RNG X 8.25LG #1 1
8. 51721498 CABLE ASM- 2GA-5/16RNG X 1/4RNG X 19.00LG #1 1
9. 51721499 CABLE ASM- 2GA-5/16RNG X 1/4RNG X 26.50LG #1 1
10. 51721664 CABLE ASM- 1GA-5/16RNGX 1/4RNGX 48.00LG #1 1
11. 51721943 CABLE ASM- 1GA-3/8RNGX SWVL FX 11.00LG #1 1
12. 51721944 CABLE ASM- 1GA-3/8RNGX SWVL MX 60.00LG #1 1
13.
14. 51721718 CABLE ASM- 2GA-5/16RNGX 3/8RNGX 25.00LG #1 2
15. 77441534 SWITCH-225A CONTACTOR 12V OR 24V 1
16. 77441312 CABLE ASM-10GA-#10RNGX 1/4RNGX 6.00LG #1 1
17. 77441303 TERM INSUL BLK #8-2 GA WIRE 1
18. 77441302 TERM INSUL RED #8-2 GA WIRE 1
19. 72060021 CAP SCR .31-18X .50 HH GR5 Z 1
20. 72063050 WASHER .31 LOCK 1
REV. L
NOTES:
1. Wrap winch cables with Black Spiral Wrap.
2. Torque to 8-15 ft-lbs (2 places).
