IMT 4004i Parts & Specifications

Electrical & Lighting 83 Section - 5
4004i - Manual # 99904386
99906234-5
BOOM TIP LIGHT INSTALL/RETROFIT
AND RE-TIGHTEN NUT TO 10-15 FT-LB
UNSCREW 1/4" SCREW, ATTACH 1/4" WASHER
CONNECTOR AND RE-TIGHTEN TO 5 IN-LB
BOLT TO BACK OF MAST WITH
1/4" BOLT, WASHERS, AND NUT PROVIDED
PLUG 3-WAY FEMALE CONNECTOR INTO NEW REEL
WITH 3 PRONG MALE CONNECTOR
PLU
GS INTO J9 ON CRANE HARNESS
(WAS PLUGGED INTO OLD REEL)
HARNESS AND SWITCH ARE PLACED THROUGHBACK OF MA
ST
AND SWITCH IS BOLTED TO BACK BOTTOM HOLE IN COVER
