17
CONVERTING THE REGULATOR
The Dual Gas Regulator has been factory set to
natural gas. To convert the Regulator for use with
liqueed petroleum gas, follow the steps below.
1. Using a special tool, open the top cover of
the regulator by screwing counter-clockwise
(Figure 7A). Figure 7B shows the Factory set
state of the top cover with adapter.
2. Remove the adapter from the top cover
(Figure 7C).
3. Invert the adapter within the top cover as per
Figure 7D.
4. Reinsert the top cover into the Regulator.
NOTE: Do not adjust the regulator valve body
piece in the above procedure, as it will aect the
performance parameters set in the factory.
WARNING: The regulator valve outlet pressure
has been set at the factory. Please do not adjust
it in order to avoid the potential occurrence of
a safety accident. If you nd any abnormality
with the regulator valve, stop use immediately
and contact our After Sales Service Team for
assistance and replacement.
Figure 7A
Figure 7B
Figure 7C Figure 7D
