2.4 Optional TS-LLD –
Tank Sentinel ATG Console
Interface
TS-1000 Tank Gauge Interface
The TS-LLD can be interfaced to an INCON TS-1000 console with the addition of
a TS-TGI module. The TGI module (Tank Gauge Interface module) can interface
up to 4 TS-LLD systems with the TS-1000. NOTE – The devices and installation
methods covered in this Section have not been evaluated by Underwriters
Laboratories and are not considered part of this Listing.
For Installation, Programming, and Testing issues of the TS-LLD & TS-1000 tank
gauge console see the INCON, TS-TGI Installation Guide, manual P/N 000-1051.
Contents:
• TS-1000 TS-TGI Interface
• TS-2000 Interface
• TS-1001 / TS-2001 LLDI Interface
EFI
Figure 2.4-1 TS-1000 & TS-TGI Hardware Layout (Motor Control Boxes not shown)
