Figure 10: "O" quick coupling type
"O" joint connecon:
1. Remove covers.
2. Check that the gasket seal on the male joint is lubricated with system uid.
3. Move the female joint and ghten the rotang nut on the male joint.
4. Insert half the joints by hand to ensure correspondence with threading, using
appropriately sized spanners (in the hexagonal body of the joint and the unit
nut) unl the two sides are connected to the boom or unl you feel denite
resistance.
5. Use a marker or a pen to mark the line in the direcon of the length from the joint
nut to the division, adding another 1/6 or 1/4 of a turn. Line misalignment will
act to indicate the degree of ghtening. The nal turn has the purpose of ensuring
that the metal edge enters into the brass housing of the two joint components,
forming a leak-proof connecon. Tightening torque values must be complied with.
