8.3 LED
A 10 mA LED connected as per the electronic diagram can be used al in order to
report errors in the electronic unit: the LED ashes a number of mes equal to the
error code. Each ash lasts 1/4 of a second. A series of ashes is followed by a period
of shut-down, at the end of which the signalling cycle re-starts and repeats every 4
seconds.
It is possible to determine the type of error in the electronic unit based on the
number of ashes, as shown in the table.
Table 7: Type of electronic unit error based on the number of LED unit ashes
# of ashes Type of error
6
Thermostat malfuncon
If the NTC thermistor is in short circuit or disconnected
5
Thermal deacvaon by the electronic unit
If the cooling system is overloaded or the environmental tempera-
ture is too high, the electronic unit overheats
4
Minimum rotaon speed
If the cooling system is overloaded, the motor cannot maintain
minimum rotaon speed around 1850 rpm
3
Motor start-up
The rotor is blocked or excessive dierenal pressure is present in
the cooling system (> 5 bar)
2
Deacvaon due to fan overcurrent
The fan loads the electronic unit with a current exceeding 0.5 A
1
Deacvaon due to baery protecon
Power voltage is outside the permissible range
