Indel Webasto Compact Classic - Page 9

Table 3: Summary of Volumes/Insulaons
INSULATION
T =
30mm
30 < T <=
50 mm
50 < T <=
80 mm
80 < T
<= 100
mm
100 < T
<= 120
mm
120 < T
<= 150
mm
150 < T
<= 200
mm
-18°C FREEZER LITRES
V <= 20 SN ST - T
20 < V <= 25 SN ST - T
25 < V <= 40 SN - ST - T
40 < V <= 55 SN ST -T
55 < V <= 65 SN ST-T
65 < V <= 85 SN - ST T
85 < V <= 130 SN ST T
130 < V <= 140 SN ST T
140 < V <= 200 SN ST - T T
The following tables contain the conguraons of the compressor and evaporator
available for air-cooled models.
Table 4: Summary of conguraons
Model Compressor Evaporator Dimensions Refrigerator
volume in L
Freezer
volume in L
GE80 BD35 Flat 350X250 80 26
GE150 BD35 Flat 386X361 150 50
2001 BD35 Oval 240X85X210 125 41
2301 BD35 Oval 320X100X230 150 50
2501 BD50 Oval 380X140X270 200 66
2005 BD35 Flat 350X130 60 20
2007 BD35 L 250+110X350 100 33
2010 BD35 L 400+170X210 125 41
2012 BD50 Flat 815X210 170 56
2016 BD50 Flat 1200X190 200 66
2017 BD50 Flat 1000X270 260 86
2013 BD50 Flat 1370X300 400 133
The refrigerator units are suitable for use with 12 Vdc or 24Vdc DC voltage systems. It
can be connected to 115VAC - 230VAC electrical mains using accessories, described
later in this manual.
