Using Keyrah V3
The following keyboards can be selected with jumpers on the C16 pin header. Note that the
“Manual Keyboard select” jumper (5 – 4) must be set for any jumpers to be detected.
Mode Jumper Pins
PS/2 Pos H 19 - 18 5 - 4
Atari ST Pos F 16 - 15 5 - 4
PC XT Pos E 14 - 13 5 - 4
SX64 Pos A 7 - 6 5 - 4
13
