Individual Computers Keyrah v3 - Pinout Information; DE9 Connector Pinout

Appendix
4.2 Pinouts
4.2.1 DE9 Connectors
1 o o o o o 5
6 o o o o 9
The joystick ports are wired the same way as on a C64:
Pin Function
1 Up
2 Down
3 Left
4 Right
5 POT Y
6 Fire
7 +5V (max. 100 mA)
8 GND
9 POT X
For much more elaborate technical information about this port, visit our wiki at
http://wiki.icomp.de/wiki/DE-9_Joystick
