Using Keyrah V3
3.6.2 C128
The C128 keyboard is a C64 keyboard (see above) with 26 extra keys.
To use the C128 keyboard in VICE, use the Keyrah V3 specific keymap that is provided with VICE
– without that a handful keys will not work as expected, in particular the “locking” keys.
12 extra keys at the top of the keyboard:
C128-key US layout DE layout
Switch down
(normal)
Switch up
(emulator)
Switch down
(normal)
Switch up
(emulator)
ESC ESC F9 ESC F9
TAB TAB F10 TAB F10
ALT right ALT F11 right ALT F11
Ascii/DIN caps-lock F12 caps-lock F12 Locking Key
HELP Numlock F2 Numlock F2
Linefeed end F6 end F6
40/80 disp F8 F4 F8 F4 Locking Key
NoScroll scroll lock F8 scroll lock F8
Arrow Up Cursor Up Cursor Up Cursor Up Cursor Up
Arrow Down Cursor Down Insert Cursor Down Insert
Arrow Left Cursor Left Cursor Left Cursor Left Cursor Left
Arrow Right Cursor Right Delete Cursor Right Delete
14 extra keys on the Numblock:
C128-key Mapped Key
0 … 9 NP 0 … 9
+ NP Add
- NP Substract
Enter NP Return
, NP Decimal
To use the Numblock in VICE, disable the “Allow keyset joysticks” setting
