2. Control cabinet design
Fig. 9: Drilling pattern for the cabinet rear wall (for assembly clearance, see also Fig. 10)
Assembly clearance Assembly clearance
M 6
373
±0,2
Minimum clearance
80 mm
Bohrbild
View of the inside of the cabinet rear wall
M 6
Minimum thickness
of mounting panel
or cabinet rear wall:
3mm for steel
6mm for aluminium
M 6
60
