Indramat TDA 1 - Page 18

18
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
2. Control cabinet design
110 ±0.5
155 ±0.5
KDV 3.1
TDA1.1 TDM 1
TDM 2
110 ±0.5 155 ±0.5
KDV 1
KDV 2
TDA 1.1
KDS
Minimum
clearance
80
137 ±0.5
TDA 1.1
TDM3
TDM4
155 ±0.5
TDA 1.1
TDA 1.1
MontAb
TVD
TVM
110 ±0.5
110 ±0.5
Fig. 10: Assembly clearance; distances between adjacent units in the drive
equipment package and top clearance
