INDUCS INSTINCT Hob 5 - Operating Conditions; Weights; INSTINCT User Manual Rev 01

18 INSTINCT User Manual rev 01 04/18
Installation Section 2
y = min 0mm [0”]
a = min 40mm
[1.57”]
a = min 40mm [1.57”]
y = min 0mm [0”]
a = min 40mm
[1.57”]
a = min 40mm [1.57”]
OPERATING CONDITIONS
For the appliance to function properly, the fol-
lowing conditions must be maintained.
Maximum Tolerance
of the Nominal Sup-
ply Voltage
+6 /-10 %
Supply frequency 50/60 Hz
Ingress Protection
class
IP X3
Minimal Diameter of
Induction Pan
12cm [5”]
Maximum Ambient
Temperature
In Storage,
-20°C to +70°C
[-4°F to +158°F]
In Operation,
+5°C to +40°C
[+41°F to +104°F]
Maximum Relative
Air Humidity
In Storage, 10% to 90%
In Operation, 30% to
90%
Noise level < 43dB
WEIGHTS
Model Net Weight
kg lb
INSTINCT
Hob 3.5
12 27
INSTINCT Hob 5 14 31
INSTINCT
Hob 10
21 47
INSTINCT
Wok 3.5
14 31
INSTINCT Wok 5 16 36
INSTINCT Wok 8 18 40
