CHILD
WITH INBUILT HARNESS
SHOULDER SLOT HEIGHT
Place the child restraint in desired upright or reclined
position, with the back against the back of the vehicle
seat, directly in line with the anchorage point (see
Figure 1).
Install the upper anchorage tting as shown on page
3 & 4 of these instructions
(Using Lap-sash Seat Belt)
IMPORTANT
!
Ensure that you use the FORWARD-FACING
BELT PATH indicators, marked in “yellow”.
CHILD
WITH INBUILT HARNESS
PULL
IMPORTANT
!
Do not use the restraint with harness shoulder
straps set at different heights.
Ensure that all straps have been secured
correctly by pulling on each strap.
Ensure that the harness straps are not twisted.
Figure 1
Figure 4
Figure 2
Step 4:
Thread each shoulder harness strap back onto the
“G” connecting plate through the gate (see Figure 3).
The shoulder harness straps are connected to the
“G” connecting plate (see Figure 2).
Figure 4
Figure 3
12
To Next Page
