Liquid crystal display (LCD)
LCD Meaning
off no supply voltage
lit green measurement / parameter mode
lit red error
The display can be rotated by 180 ° via the diagnostic
port.
Put the gauge into operation
When the supply voltage is applied
the software version is briefly dis-
played.
