52
tina56e1-f (2015-09)
<STATUS MOD> (gauge status):
LED Meaning
off No supply
blinking green-red Selftest
lit solid green Normal operation
lit solid red Non recoverable error
blinking red Recoverable error (e.g. missing
DeviceNet power supply)
<STATUS NET> (network status):
LED Meaning
off Gauge not online:
• Selftest not yet concluded
• No supply, → "STATUS MOD"
blinking green Gauge online but no communication:
• Selftest concluded but no communica-
tion to other nodes established
• Gauge not assigned to any master
lit solid green Gauge online; necessary connections
established
blinking red One or several input / output connections in
"time out" status
lit solid red Communication error. The gauge has de-
tected an error that impedes communica-
tion via the network (e.g. two identical node
addresses (MAC IC) or "Bus-off")
