User Manual AURIX™ TCxx4 lite Kit
AURIX™ TCxx4 lite Kit
1 Introduction
1 Introduction
This document describes the features and hardware details of the AURIX™ TCxx4 lite Kit equipped with a
32-Bit Single-Chip AURIX™ TriCore™-based Microcontroller TC334, TC324, TC234, TC224 or TC214 from
Infineon Technologies AG.
It can be used with a range of development tools including Infineon’s free of charge Eclipse based IDE AURIX™
Development Studio or the Eclipse based “FreeEntryToolchain” from HighTec/PLS/Infineon. AURIX™
Development Studio is a comprehensive environment, including C-Compiler and Multi-core Debugger,
Infineon’s low-level driver (iLLD), with no time and code-size limitations that enables editing, compiling and
debugging application code. The FreeEntryToolchain is a full C/C++ development environment which has a
source-level UDE debugger from PLS included and is also based on Infineon low-level driver (iLLD).
Table 1 shows the overview specifications of the whole board.
Table 1 Overview of the Board Specification
CPU Core AURIX™
Manufacturer Order No.
SAK-TC334LP-32F300F AA
Manufacturer Order No.
SAK-TC324LP-16F160F AA
Manufacturer Order No.
SAK-TC234LP-32F200N AC
Manufacturer Order No.
SAK-TC224L-16F133N AC
Manufacturer Order No.
SAK-TC214L-8F133N AC
Board Dimensions
66.0 x 131.0 mm
Power
• on-board miniWiggler Micro-AB USB interface
• external powering 5 V…40 V (recommended 7 V...14 V)
Connectors
• Most AURIX™ pins available on expansion connectors (X1, X2)
• Two Infineon Shield2Go connectors
• Arduino compatible connectors for 3.3 V
• mikroBUS™ connector
• Micro-USB connector
• DAP Debug connector
• CAN connector
Others
• CAN transceiver TLE9251VSJ from Infineon
• 1 user push-button, 3 user LEDs
• Reset push-button
• Potentiometer (10 kOhm) for variable analog input
These boards are neither cost nor size optimized and do not serve as a reference design.
