Infineon SAK-TC375TP-96F300W AA - Debugging and on board miniWiggler

AURIX™ lite Kit V2
Hardware Description
Board Users Manual 11 Revision October, 2020
Table 3 miniWiggler Pin Mapping for User LEDs
Name
miniWiggler Pin
Color
Active
LED5
ADBUS4 (ACTIV)
green
Low-active (pull against GND)
LED6
ADBUS7 (RUN)
green
Low-active (pull against GND)
Table 4 AURIX™ Push Buttons and Potentiometer
Name
AURIX™ Pin
Active
Button1
P00.7
Low-active (pull against GND)
Reset
/PORST
Low-active (pull against GND)
R32 (10kΩ)*
AN0
-
*Note: Desoldering resistor R33, enables AN0 for other functions, but disables the Potentiometer functionality.
2.3 Debugging and on board miniWiggler
The AURIX™ lite Kit V2 supports debugging via 2 different channels:
 On-board miniWiggler via the the microUSB X4
 10-pin DAP Connector
2.3.1 USB Connector
The USB connector is used for connection to a PC. Via the USB it is possible to power the board, using the
ASCLIN0 as serial connection via USB and Debugging via DAS.
NOTE: Before connecting the board to the PC, make sure that the actual DAS software is installed on
the PC.
For actual DAS software please contact your local FAE.
The software can also be found on:
DAS website
2.3.2 Serial Connection to PC
After the first connection of USB to a PC the needed driver will be installed automatically. During this there will
be created a new COM port on PC. This COM port can be used to communicate with the board via ASCLIN0 of
the device and ASCLIN4 (TC3X5 only) if R44 and R45 are assembled. Per default the ASCLIN0 is used on
P14.0 and P14.1 (e.g. Generic Bootstrap Loader). Because ASCLIN0 is used also for the Arduino pins, you can
use here also ASCLIN4 to use it in parallel, make sure that P14.0/P14.1 are not configured in this case.
