1 Introduction
This document describes the features and hardware details of the AURIX™ lite Kit V2 equipped with a
32-Bit Single-Chip AURIX™ TriCore™-based Microcontroller TC375, TC365, TC275 or TC265 from Infineon
Technologies AG.
It can be used with a range of development tools including Infineon’s free of charge Eclipse based IDE AURIX™
Development Studio or the Eclipse based “FreeEntryToolchain” from Hitecs/PLS/Infineon. AURIX™
Development Studio is a comprehensive environment, including C-Compiler and Multi-core Debugger, Infineon’s
low-level driver (iLLD), with no time and code-size limitations that enables editing, compiling and debugging
application code. The FreeEntryToolchain is a full C/C++ development environment which has a source-level
UDE debugger from PLS included and is also based on Infineon low-level driver (iLLD).
Table 1 shows the overview specifications of the whole board.
Table 1 Overview of the Board Specification
CPU Core AURIX™
Manufacturer Order No.
SAK-TC375TP-96F300W AA
Manufacturer Order No.
SAK-TC365DP-64F300W AA
Manufacturer Order No.
SAK-TC275TP-64F200W DC
Manufacturer Order No.
SAK-TC265D-40F200W BC
Board Dimensions
66.0 x 131.0 mm
Power
 on-board miniWiggler Micro-AB USB interface
 external powering 5 V…40 V (recommended 7 V...14 V)
Connectors
 Most AURIX™ pins available on expansion connectors (X1, X2)
 Two Infineon Shield2Go connectors
 Arduino compatible connectors for 3.3 V
 mikroBUS™ connector
 Micro-USB connector
 DAP Debug connector
 CAN connector
 RJ45 connector
Others
 CAN transceiver TLE9251VSJ from Infineon
 Low Power 10/100 Mbps Ethernet Physical Layer Transceiver DP83825I from TI
 1 user push-button, 3 user LEDs
 Reset push-button
 Potentiometer (10 kOhm) for variable analog input
These boards are neither cost nor size optimized and do not serve as a reference design.
