TECHNICAL DATA –INFINEA TAB M
* Specifications subject to change without notice.
Electrical
Power supply
Internal voltage 3.3V & 5V
Compatibility
iPad mini
Communications
USB Interface – between Infinea TAB mini and iPad mini
USB Synchronization between Apple iPad mini ® & PC
Power Consumption
Deep sleep ~20uA
Magnetic Stripe Reader
3-track bidirectional reading capabilities
Type: ISO 7816-1/2/3 compatible & RAW mode
Encryption Methods
3DES-112 with DUKPT Key Management
AES-256 with Fixed Key Management
Optional: AES-128 with Fixed Key Management
Barcode Scanner
2D High Speed Imager
Barcode Type
2D Supported Symbologies:
Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F,
Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code
(mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417
1D Scanner Supported Symbologies:
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code
93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial
2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/Plessey, S-
Code, Telepen, Tri-Optic, UK/Plessey
RFID Reader (Optional)
MIFARE MINI
MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
MIFARE ULTRALIGHT, ULTRALIGHT-C
ISO 14443, ISO 15693
MIFARE PLUS 2K/4K
DESFire cardm FeLiCa
Bluetooth
Communication
Bluetooth 2.0 Class 2
Distance – Up to 10m
Serial Port Profile (SPP)
LEDs
Green LED for battery
Blue LED for device status
Four LEDs for Contactless indication
Buttons
Scan and status buttons
Battery
Rechargeable Li-ion Battery 3.7V/1100mAh, charging from USB port
or charging station
Cables
Standard USB A to mini B Cable (0.9m)
Audio Indicator
Audio magnetic buzzer
Mechanical
Dimensions
103mm (L) x 88mm (W) x 23.5mm (H)
Weight
140 grams (without iPad mini)
Environment
Operating Environment
- Operating temperature 0°C to +40°C
- Operating humidity 35 to 85% RH
- Storage temperature -5°C to +40°C
- Storage humidity 10 to 90% RH
Certifications
PCI
PTS 3.x SRED compliant (optional)
