InfiRay TD50L User Manual

Composition and Description of Main Menu
Wi-Fi
Enabling/Disabling Wi-Fi

Press and hold the rotary encoder (7) to open the advanced menu;

Turn the rotary encoder (7) to select the "Wi-Fi" function option;

Press the rotary encoder (7) to enable/disable Wi-Fi;

The icon in the status bar changes accordingly after this mode is turned on or
off.
Reticle
Selecting Zeroing Profile
 Press and hold the rotary encoder (7) to open the advanced menu;
 Turn the rotary encoder (7) to select the "Zeroing Profile" function option;
 Press the rotary encoder (7) to open the secondary menu of "Zeroing Profile";
 Turn the rotary encoder (7) to select one from the three zeroing profiles (A, B,
C);
 Press the rotary encoder (7) to confirm the selection, and return to the main
menu.
 The operation for reticle style and reticle color is the same as that for zeroing,
which can be set up separately.

InfiRay TD50L Specifications

General

Objective lens diameter	50 mm
Pixel size	12 μm
Frame rate	50 Hz
Display type	AMOLED
Sensor resolution	384x288 pixels
Digital zoom	4x
Thermal Sensitivity	<40mK
Spectral Range	8-14μm
Display	1.03-inch
Operating Temperature	-20°C to +50°C
