InFocus IN114BBST User Manual

RS232 Commands
頁 4
Model Name Notes
RS232 Setting
IN112AA
IN114AA/V11
IN116AA/V13
IN118AA
IN119AA
(w/o RS232)
IN112BB
IN114BB
IN114BBST/V31
IN118BB
IN118BBST
IN116BB
IN116BBST
IN119BB
IN188DD
Baud Rate: 9600; Data Bits: 8; Pari ty: None; Stop Bits: 1; Flow Control: None; UART16550 FIFO: Disabl e
Projector Return (Pass): P; Projector Ret urn (Fail): F
XX= 00-99 (Pojector's ID), XX= 00 is for all projectors
Note :
1. There i s a <CR> after all ASCII commands
2. 0D is the HEX code for <CR> in ASCII code
ASCII Code HEX Code
R002 ~XX108 1 7E 30 30 31 30 38 20 31 0D
Lamp Hours
aaaaa=(5 digits) Total
Lamp Hours
Okaaaaa No Yes Yes Yes Yes
R003 ~XX121 1 7E 30 30 31 32 31 20 31 0D
Input Source Commands
a=0, None
a=1, HDMI (HDMI 1)
a=5, VGA
a=9, S-Video
a=10, Video
a=15, HDMI 2
Oka No Yes Yes Yes Yes
R004 ~XX122 1 7E 30 30 31 32 32 20 31 0D
Software Version
aaaa=Software Version
Okaaaa No Yes Yes Yes Yes
R005 ~XX123 1 7E 30 30 31 32 33 20 31 0D
Display Mode
a=0, None
a=1, Presentation
a=2, Bright
a=3, Movie (Cinema)
a=4, sRGB
a=5, User
a=9, 3D
a=13, DICOM SIM.
a=14, ISF Day
a=15, ISF Night
Oka No Yes Yes Yes Yes
R006 ~XX124 1 7E 30 30 31 32 34 20 31 0D
Power State
a=0, Off
a=1, On
Oka No Yes Yes Yes Yes
R007 ~XX125 1 7E 30 30 31 32 35 20 31 0D
Brightness
aaa=-50~+50
Okaaa No Yes Yes Yes Yes
R008 ~XX126 1 7E 30 30 31 32 36 20 31 0D
Contrast
aaa=-50~+50
Okaaa No Yes Yes Yes Yes
R009 ~XX127 1 7E 30 30 31 32 37 20 31 0D
Aspect Ratio
aa=0, None
aa=1, 4:3
aa=2, 16:9
aa=3, 16:10
aa=5, LBX
aa=6, Native
aa=7, Auto
Okaa No Yes Yes Yes Yes
R010 ~XX128 1 7E 30 30 31 32 38 20 31 0D
Color Temperature
a=1, Warm
a=2, Medium
a=3, Cold
Oka No Yes Yes Yes Yes
R011 ~XX129 1 7E 30 30 31 32 39 20 31 0D
Projection Mode
a=0, Front
a=1, Rear
a=2, Front-Ceiling
a=3, Rear-Ceiling
Oka No Yes Yes Yes Yes
R012 ~XX150 1 7E 30 30 31 35 30 20 31 1D
Information
a=Power Status
a=0, Power Off
a=1, Power On
bbbbb=Lamp Hours
cc=Input Source
cc=00, None
cc=01, HDMI (HDMI 1)
cc=05, VGA
cc=09, S-Video
cc=10, Video
cc=15, HDMI 2
dddd=Software Version
ee=Display Mode
ee=00, None
Okabbbbbccddddee No Yes Yes Yes Yes
R013 ~XX150 4 7E 30 30 31 35 30 20 34 0D
Resolution
a=string (e.g.
Ok1920x1080)
Oka No Yes Yes Yes Yes No signal (a=Ok0x0)
R015 ~XX150 19 7E 30 30 31 35 30 20 31 39 0D
Refresh rate
a=string (e.g. Ok60Hz)
Oka No Yes Yes Yes Yes No signal (a=Ok0Hz)
R016 ~XX151 1 7E 30 30 31 35 31 20 31 0D
Model Name
a=1, SVGA
a=2, XGA
a=3, WXGA
a=4, 1080p
a=5, WUXGA
Oka No Yes Yes Yes Yes
R017 ~XX108 1 7E 30 30 31 30 38 20 31 0D
Lamp Hours
aaaaa=00000~99999
Okaaaaa No Yes Yes Yes Yes
R018 ~XX321 1 7E 30 30 33 32 31 20 31 0D
Filter Usage Hours
aaaaa=00000~99999
Okaaaaa No No No No No
R019 ~XX352 1 7E 30 30 33 35 32 20 31 0D
System Temperature
aaa=000~999
Okaaa No Yes Yes Yes Yes
R020 ~XX353 1 7E 30 30 33 35 33 20 31 0D
Serial Number
a=string
Oka No Yes Yes Yes Yes
R022 ~XX355 1 7E 30 30 33 35 35 20 31 0D
AV Mute
a=0, Off
a=1, On
Oka No Yes Yes Yes Yes
R023 ~XX356 1 7E 30 30 33 35 36 20 31 0D
Mute
a=0, Off
a=1, On
Oka No Yes Yes Yes Yes
R025 ~XX543 1 7E 30 30 35 34 33 20 31 0D
H Image Shift
aaaa=-100~+100
Okaaaa No Yes Yes Yes Yes
R026 ~XX543 2 7E 30 30 35 34 33 20 32 0D
V Image Shift
aaaa=-100~+100
Okaaaa No Yes Yes Yes Yes
R027 ~XX543 3 7E 30 30 35 34 33 20 33 0D
V Keystone
aaa=-40~+40
Okaaa No Yes Yes Yes Yes
R028 ~XX558 1 7E 30 30 35 35 38 20 31 0D
Projector ID
aa=00~99
Okaa No Yes Yes Yes Yes
Note 1: ~xx112 1 ~nnnn (nnnn = password) When security is on, you need to add password after command or it will return F.
Note 2: When the projector show other OSD, user key the command “~XX313 0 7E 30 30 33 31 33 20 30 0D Information menu Off (0/2 for backward compatible)” then it will return F.
Index
Function
READ from Projector
Command Set
Projector Return
Support (Yes/No)
Notes
