48
Supported file formats
• Images
• Audio
• Voice Record
• Video
Image Format Profile Color Space Size Limitation
JPEG
Baseline YUV400 No limit
YUV420 No limit
YUV422 No limit
YUV440 No limit
YUV444 No limit
Progressive YUV400 Width <= 10240 &
height <= 6400
YUV420
YUV422
YUV440
YUV444
BMP No limit No limit No limit
Audio Format Sample rate (KHz) Bit Rate (Kbps)
OGG 8-48 64-320
ADPCM-WAV 8-48 32-384
PCM-WAV 8-48 128-1536
AAC 8-48 8-256
File Format Audio Format Sample rate (KHz) Bit Rate (Kbps)
.wav IMA-ADPCM 8 32
16 64
24 192
48 384
File
Extensions
Audio/Video Codec Profile/
Level Support
Explanation
.avi
.divx
.mkv
Video
MJPEG No limitations
H.264/AVC Up to High Profile ,
Levels 1- 4.1 (1080P
30fps 20Mbps)
Only supports 1-3
reference frames.
XVID Up to Advance Simple
profile (1080P 30fps
20Mbps)
MPEG2 Main profile, Low and
Main Levels (1080P
30fps 20Mbps)
MPEG4 Advanced Simple Profile
(frame picture) , Levels
0-5 (1080P 30fps
20Mbps)
.ts Video
MPEG2 Main profile, Low and
Main Levels (1080P
30fps 20Mbps)
H.264/AVC Up to High Profile ,
Levels 1- 4.1 (1080P
30fps 20Mbps)
Only supports 1-3
reference frames.
.dat
.vob
.mpg
.mpeg
Video
MPEG1 Main profile, Low and
Main Levels (1080P
30fps 20Mbps)
D-frames used for
fast previews are
not supported.
MPEG2 Main profile, Low and
Main Levels (1080P
30fps 20Mbps)
Audio
MPEG-1 Layer
I, II
MPEG-1 Layer
III (mp3)
.mov
.mp4
Video
MPEG4 Advanced Simple Profile
(frame picture) , Levels
0-5 (1080P 30fps
20Mbps)
H.264/AVC Up to High Profile ,
Levels 1- 4.1 (1080P
30fps 20Mbps)
Only supports 1-3
reference frames.
