InFocus IN5122 Quick Start Guide

7
ENGLISH
Connecting with your devices
Before connecting the projector to a device, consult the device manual to conrm
that the device is suitable for connecting with this projector and prepare required
accessories, such as a cable compatible with the signal of the device. Consult your
dealer when the required accessory did not come with the product or the accessory
is damaged.
After making sure that the projector and the devices are turned off, perform the
connection, according to the following instructions. Refer to gures F-1 to F-4 at the
back of this manual.
For details, see the User’s Manual. Before connecting the projector to a network
system, be sure to read the Network Guide too.
WARNING ►Only use appropriate accessories. Otherwise a re or dam-
age to the projector and devices may occur.
►Only use the accessories specied or recommended by the projector’s
manufacturer. The manufacturer may be following a regulation standard.
► Do not disassemble or modify the projector or its accessories.
►Do not use a damaged accessory. Avoid damaging the accessories. Route
cables so they are not stepped on or pinched.
CAUTION ►For a cable with a core at only one end, connect the end with
the core to the projector. This may be required by EMI regulations.
►Before connecting the projector to a network system be sure to obtain the
consent of the network administrator.
►Do not connect the LAN port to any network which may have excessive volt-
age.
►Before removing a USB storage device from the port of the projector, be
sure to use the REMOVE USB function on the thumbnail screen to protect your
data.
NOTE • Do not turn the projector on or off while it is connected to an
operating device, unless directed to do so in the device manual.
• Some input ports are selectable. For details, see the User’s Manual.
• Be careful not to mistakenly connect a connector to an incorrect port.
• If an oversized USB storage device blocks the LAN port, use a USB extension
cable to connect to the USB storage device.
• If loud feedback noise is produced from the speaker, move the microphone
away from the speaker.
• This projector does not provide power to the microphone.

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
