InFocus IN5122 Quick Start Guide

2
Safety Information
Entries and graphical symbols explanation
The following entries and graphical symbols are used throughout the manuals for
safety purposes. Please familiarize yourself with these items and pay particular
attention when you see them.
Important safety instruction
The following are important instructions for safely using the product. Always fol-
low these instructions when handling the product. The manufacturer assumes no
responsibility for any damage caused by mishandling that is beyond normal usage
as dened in the manuals for this projector.
WARNING This entry warns of a risk of serious personal injury or even death.
CAUTION This entry warns of a risk of personal injury or physical damage.
NOTICE This entry points out important information to keep your
projector in working order.
WARNING ►Never use the projector if it is acting abnormally (i.e. it is
smoking, smelling strangely, has liquid or a foriegn object inside, or is broken,
etc.). If such an event should occur, unplug the projector immediately.
►Keep the projector away from children and pets.
►Do not use the projector in the event of thunderstorms.
►Unplug the projector from the power outlet when the projector is not being
used.
►Do not open or remove any portion of the projector, unless the manuals
specify to do so. Internal maintenance should be left to your dealer and their
service personnel.
►Use only accessories specied or recommended by the manufacturer.
►Do not modify the projector or accessories.
►Do not allow liquids or other substances to enter the projector.
►Do not allow the projector to get wet.
►
Do not place the projector where any oils, such as cooking or machine oil, are
used. Oil may harm the projector, cause the projector to malfunction or cause
the projector to fall from its mounted position.
►Do not apply shock or pressure to this projector.
►Do not place the projector on an unstable place such as an uneven surface
or leaning table.
►Do not place the projector unstably. Place the projector so that it does not
protrude from the surface it is placed on.
►Remove all attachments from the projector, including the power cord and
cables, before carrying the projector.
► Do not look into the lens or any projector openings, while the lamp is on.
► Do not go near the lamp door or exhaust vents, while the projection lamp is on.
Also if the lamp goes out, do not touch the lamp until it has had time to cool down.

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
