12
Replacing the lamp
Lamps have a nite product life. Using the lamp for long periods of time can cause
the pictures to become dim and the color tone to become poor. Each lamp has a
different lifetime, and some may burst or burn out soon after you start using them.
Purchasing a replacement lamp ahead of time is recommended. To purchase
a new lamp, contact with your dealer and ask for the following the lamp part
number.
Part number : SP-LAMP-064
1.
Turn the projector off, and unplug the power cord.
Allow the projector to cool for at least 45 minutes.
2.
Purchase a new lamp. If the projector is mounted
on a ceiling, or if the lamp has broken, you can
ask the dealer to replace the lamp.
If you replace the lamp yourself, follow these
procedures:
3.
Loosen the screw (marked by an arrow) on the
lamp door and then slide and lift the lamp door to
the side to remove it.
4.
Loosen the 3 screws (marked by arrows) on the
lamp, and slowly remove the lamp using the
handles. Never loosen any other screws.
5.
Insert the new lamp, and retighten the 3 screws on
the lamp rmly (which were previously loosened)
to lock it in place.
6.
Slide the lamp door back in place. Then rmly
fasten the screw on the lamp door.
7.
Turn the projector on and reset the lamp time
using the RESET LAMP HOURS item in the
SERVICE menu.
(1) Press the MENU button to display a menu.
(2) Point at the ADVANCED MENU in the menu using the
V / Λ button, then press the > button.
(3) Point at the OPTION in the left column of the menu
using the V / Λ button, then press the > button.
(4) Point at the SERVICE in the menu using the V / Λ button,
then press the > button.
(5) Point at the RESET LAMP HOURS using the V / Λ button,
then press the > button. A dialog will appear.
(6)
Press the
>
button to select YES on the dialog. This resets the lamp time.
CAUTION ►Do not touch anywhere inside of area where the lamp was
removed from the projector.
Lamp door
4
3
6
Handles

Other manuals for InFocus IN5122

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN5122 and is the answer not in the manual?

InFocus IN5122 Specifications

General IconGeneral
Matrix size0.63 \
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)2000:1
Screen size compatibility35.4 - 358 \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
FocusManual
Throw ratio1.5 - 2.5:1
Zoom capabilityYes
Focal length range- mm
Vertical lens shift range-20 - 0 °
Horizontal lens shift range-20 - 20 %
Lamp typeUHP
Lamp power245 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
3D-
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions1600 x 1200 (UXGA)
RMS rated power16 W
Number of built-in speakers2
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Ethernet LAN data rates10, 100 Mbit/s
Cables includedAC, RCA, VGA
Power consumption (standby)- W
Noise level32 dB
CertificationUL, c-UL, FCC, CE
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Cable lock slot typeKensington
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth318.5 mm
Width401 mm
Height111 mm
Weight4800 g
Package depth420 mm
Package width560 mm
Package height197 mm
Package weight8200 g
